Rev. A Parts List Appendix E-9
TM-H6000/H6000P Service Manual
Confidential
Support plate PLATE,SUPPORT,A 1 F-1 137
Table holder HOLDER,TABLE 1 F-1 138
Operation label (type BA) LABEL,OPERATION,BA 1 F-1 139
Operation label (type CA) LABEL,OPERATION,CA 1 F-1 140
Front seal SEAL,FRONT 1 F-1 141
Operation label (type DA) LABEL,OPERATION,DA 1 F-1 142
Hexagon lock screw (inch type) HEXAGON LOCK SCREW 2 F-1 144
Hexagon lock screw (millimeter type) HEXAGON LOCK SCREW 2 F-1 144
Power switch cover COVER,POWER SWITCH 1 F-1 145
Switch panel label LABEL,SWITCH PANEL 1 F-1 146
Main circuit board assembly (for TM-H6000/
H6000P)
MAIN CIRCUIT BOARD ASSEMBLY (FOR TM-
H6000/H6000P)
1 F-1 201
RS-232 I/F circuit board assembly RS-232 I/F CIRCUIT BOARD ASSEMBLY 1 F-1 202
Earth wire assembly EARTH WIRE ASSEMBLY 1 F-1,3 203
Thermal unit sensor circuit board assembly THERMAL UNIT SENSOR CIRCUIT BOARD
ASSEMBLY
1 F-1 204
Thermal head FFC FFC,THERMAL HEAD 1 F-1 205
Intermit circuit board cable CABLE,INTERMIT CIRCUIT BOARD 1 F-1 206
Power switch cable assembly POWER SWITCH CABLE SET 1 F-1 207
Switch panel circuit board assembly SWITCH PANEL CIRCUIT BOARD ASSEMBLY 1 F-1 208
Circuit board FFC FFC,CIRCUIT BOARD 2 F-1 209
Switch panel cable CABLE,SWITCH PANEL 1 F-1 210
Thermal mechanism assembly (M-H6000) THERMAL MECHANISM ASSEMBLY (M-
H6000)
1 F-1 500
E-ring(2.5) RETAINING RING TYPE-E(2.5) 1 F-6 501
screw(C.B.P-tite,3X8) C.B.P-TITE SCREW,3X8,F/ZN 4 F-6 502
Platen shaft holder SHAFT HOLDER,PLATEN 1 F-6 503
screw(C.B.B-tite,2X8) C.B.B-TITE,2X8,F/ZN 1 F-6 504
Deceleration gear GEAR,DECELERATION 1 F-6 505
Press head spring SPRING,PRESS HEAD 2 F-6 506
Fixed blade FIXED BLADE 1 F-6 507
N.E. detector holder HOLDER,N.E.DETECTOR 1 F-6 508
N.E. detector lever LEVER,N.E.DETECTOR 1 F-6 509
Paper detector assembly PAPER DETECTOR ASSEMBLY 1 F-6 510
Platen assembly PLATEN ASSEMBLY 1 F-6 511
N.E. detector adjustment screw SCREW,DETECTOR ADJUSTMENT,N.E 1 F-6 512
Head caution seal SEAL,CAUTION,HEAD 2 F-6 513
Right frame FRAME,RIGHT 1 F-6 514
name for service manual name for price list Q’ty page Ref.#
