Appendix E-10 Parts List Rev. A
Confidential
Left frame FRAME,LEFT 1 F-6 515
Motor frame FRAME,MOTOR 1 F-6 516
Frame plate PLATE,FRAME 1 F-6 517
Frame cover COVER,FRAME 1 F-6 518
Pressurizing plate PLATE,PRESSURIZING 1 F-6 519
Relaxation plate PLATE,RELAXATION 1 F-6 520
Blade holder spring SPRING,BLADE HOLDER 1 F-6 521
Gear shaft SHAFT,GEAR 1 F-6 522
Cover spring SPRING,COVER 2 F-6 523
Cover shaft SHAFT,COVER 2 F-6 524
Thermal print head assembly THERMAL PRINT HEAD ASSEMBLY 1 F-6 525
Paper holder PAPER HOLDER 1 F-6 526
Intermit circuit board assembly INTERMIT CIRCUIT BOARD ASSEMBLY 1 F-6 527
Paper cutter frame assembly FRAME,PAPER CUTTER ASSEMBLY 1 F-6 528
Paper cutter motor sub assembly MOTOR,PAPER CUTTER SUB ASSEMBLY 1 F-6 529
Manual cutter MANUAL CUTTER 1 F-6 530
Cover tube COVER TUBE 4 F-6 532
Guard tube GUARD TUBE 1 F-6 533
Paper cutter lead wire LEAD WIRE,PAPER CUTTER 1 F-6 534
Micro switch MICRO SWITCH 1 F-6 535
Screening plate PLATE,SCREENING 1 F-6 536
Hexagon nut(3) H.N.-1,3,F/ZN 1 F-6 537
E-ring(1.5) RETAINING RING TYPE-E(1.5) 1 F-6 538
E-ring(2) RETAINING RING TYPE-E(2) F/UC 2 F-6 539
screw(C.B.S-tite F,3X6) C.B.S-TITEF,3X6,F/ZN 13 F-6 540
Sensor circuit board assembly SENSOR CIRCUIT BOARD ASSEMBLY 1 F-6 541
Micro switch MICRO SWITCH 1 F-6 542
Cover open detector lead wire LEAD WIER,COVER OPEN DETECTOR 1 F-6 543
Receipt paper feed motor MOTOR,PAPER FEED,RECEIPT 1 F-6 544
N.E. detector lead wire assembly LEAD WIRE N.E.DETECTOR ASSEMBLY 1 F-6 545
Paper cutter cover assembly COVER PAPER CUTTER ASSEMBLY 1 F-6 546
Relaxation plate fixing plate PLATE,RELAXATION PLATE FIXING 1 F-6 547
screw(C.B.,2X2.5) C.B.2X2.5,F/ZN 3 F-6 548
Switch screw SCREW,SWITCH 1 F-6 549
Mechanism assembly (M-U675, type AB) MECHANISM ASSEMBLY,AB (M-U675) 1 F-1 600
Ribbon feed spring RIBBON FEED SPRING 1 F-4 601
name for service manual name for price list Q’ty page Ref.#
To Next Page
