Rev. A Parts List Appendix E-11
TM-H6000/H6000P Service Manual
Confidential
Belt drive cap CAP,BELT DRIVE 2 F-4 602
Platen spring SPRING,PLATEN 2 F-5 603
Oil ring OIL RING 2 F-4 604
Slip insertion detector holder HOLDER,SLIP INSERT DETECTOR 1 F-3 605
Nylon clip NYLON CLIP 1 F-2 606
screw(C.P.P-tite,3X12) C.P.P-TITE SCREW,3X12,F/ZN 1 F-4 607
screw(C.B.P-tite,3X6) C.B.P-TITE SCREW,3X6,F/ZN 4 F-2,3 608
Slip feed roller shaft holder SHAFT HOLDER,SLIP FEED ROLLER 4 F-2,3 609
Carriage spring SPRING,CARRIAGE 1 F-4 610
Front reinforcement frame FRAME,FRONT REINFORCE 1 F-3 611
Front frame FRAME,FRONT 1 F-3 612
Lever drive motor detector plate DETECTOR PLATE,LEVER DRIVE MOTOR 1 F-3 613
Lever motor reduction gear GEAR,LEVER MOTOR REDUCTION 1 F-3 614
Lever drive transmission gear GEAR,LEVER DRIVE TRANSMISSION 1 F-3 615
Lever drive shaft gear GEAR,LEVER DRIVE SHAFT 1 F-3 616
Form stopper FORM STOPPER 1 F-3 617
Form stopper shaft SHAFT,FORM STOPPER 1 F-3 618
Form stopper spring SPRING,FORM STOPPER 1 F-3 619
Lever drive coil (type A) COIL,LEVER DRIVE,A 1 F-3 620
Lever drive coil (type B) COIL,LEVER DRIVE,B 1 F-3 621
Nose guide GUIDE,NOSE 1 F-4 622
Platen lever LEVER,PLATEN 1 F-5 623
Platen lever spring SPRING,PLATEN LEVER 1 F-5 624
Platen lever shaft SHAFT,PLATEN LEVER,L 2 F-5 625
Platen lever drive cam CAM,PLATEN LEVER DRIVE 1 F-2 626
Carriage belt BELT,CARRIAGE 1 F-4 627
Belt tension spring SPRING,BELT TENSION 1 F-4 628
Carriage guide shaft SHAFT,CARRIAGE GUIDE 1 F-4 629
Carriage transmission pulley PULLEY,CARRIAGE TRANSMISSION 1 F-4 630
Carriage drive pulley PULLEY,CARRIAGE DRIVE 1 F-4 631
Carriage drive transmission gear GEAR,CARRIAGE DRIVE TRANSMISSION 1 F-4 632
Paper ejection detector holder HOLDER,PAPER EJECTION DETECTOR 1 F-2 633
Paper feed transmission gear GEAR,PAPER FEED TRANSMISSION 1 F-3 634
Paper feed frame shaft SHAFT,PAPER FEED FRAME 1 F-2 635
Sub slip feed lever shaft SHAFT,SUB SLIP FEED LEVER 1 F-3 636
Slip hold roller shaft SHAFT,SLIP HOLD ROLLER 1 F-2 637
name for service manual name for price list Q’ty page Ref.#
To Next Page
