Epson TM-H6000 Service Manual

Appendix E-12 Parts List Rev. A
Confidential
Slip transmission gear GEAR,SLIP TRANSMISSION 3 F-2 638
Slip drive gear GEAR,SLIP DRIVE 4 F-2,3,5 639
Paper feed frame fixing lever spring (type
A)
SPRING,PAPER FEED FRAME FIXING LEVER,A 1 F-5 640
Sub slip feed lever spring SPRING,SUB SLIP FEED LEVER 1 F-3 641
Paper feed frame fixing lever spring (type B) SPRING,PAPER FEED FRAME FIXING LEVER,B 1 F-5 642
Slip feed roller holder HOLDER,SLIP FEED ROLLER 1 F-5 643
Sub slip feed roller holder HOLDER,SUB SLIP FEED ROLLER 1 F-3 644
Slip guide upper frame FRAME,SLIP GUID UPPER 1 F-3 645
Slip guide lower frame (type B) FRAME,SLIP GUID LOWER,B 1 F-3 646
J/S change spacer SPACER,J/S CHANGE 1 F-2 647
Sub slip hold roller ROLLER,SUB SLIP HOLD 1 F-3 648
Slip feed roller ROLLER,SLIP FEED 1 F-5 649
Slip paper guide PAPER GUIDE,SLIP 1 F-5 650
Platen ground plate (type A) PLATE,PLATEN GROUND,A 1 F-5 651
Platen ground plate (type B) PLATE,PLATEN GROUND,B 1 F-5 652
MICR shutter SHUTTER,MICR 1 F-3 653
Endorsement platen shutter SHUTTER,ENDORSEMENT PLATEN 1 F-3 654
Ribbon reduction gear GEAR,RIBBON REDUCTION 1 F-4 656
Ribbon intermediate gear GEAR,RIBBON INTERMEDIATE 1 F-4 657
Platen adjustment screw SCREW,PLATEN ADJUSTMENT 2 F-5 658
Lever drive motor assembly MOTOR,LEVER DRIVE ASSEMBLY 1 F-3 659
Sub slip feed lever sub assembly LEVER,SUB SLIP FEED SUB ASSEMBLY 1 F-3 660
Print head unit (Eb) PRINT HEAD UNIT EB 1 F-4 662
Paper ejection detector assembly PAPER EJECTION DETECTOR ASSEMBLY 1 F-2 663
Front cover detector assembly FRONT COVER DETECTOR ASSEMBLY 1 F-2 664
Lever drive shaft assembly LEVER DRIVE SHAFT ASSEMBLY 1 F-3 665
Sub slip feed roller assembly ROLLER,SUB SLIP FEED ASSEMBLY 1 F-3 666
Lever coil mounting plate sub assembly MOUNTING PLATE,LEVER COIL SUB
ASSEMBLY
1 F-3 667
Slip B.O.F. detector assembly SLIP B.O.F. DETECTOR ASSEMBLY 1 F-3 668
Platen lever frame assembly FRAME,PLATEN LEVER ASSEMBLY 1 F-5 669
Paper feed frame fixing R lever assembly LEVER,PAPER FEED FRAME FIXING R
ASSEMBLY
1 F-5 670
Slip T.O.F. detector assembly SLIP T.O.F. DETECTOR ASSEMBLY 1 F-3 671
Lever motor T.P. detector assembly LEVER MOTER T.P. DETECTOR ASSEMBLY 1 F-3 672
Main circuit board assembly (for M-U675) MAIN CIRCUIT BOARD ASSEMBLY (FOR M-
U675)
1 F-3 673
name for service manual name for price list Q’ty page Ref.#
