Rev. A Parts List Appendix E-13
TM-H6000/H6000P Service Manual
Confidential
Ribbon drive plate assembly RIBBON DRIVE PLATE ASSEMBLY 1 F-4 674
H.P. detector assembly H.P.DETECTOR ASSEMBLY 1 F-4 675
Intermediate circuit board assembly INTERMEDIATE CIRCUIT BOARD ASSEMBLY 1 F-4 676
Carriage assembly CARRIAGE ASSEMBLY 1 F-4 677
Platen assembly PLATEN ASSEMBLY 1 F-5 678
Paper feed frame fixing L lever (type B)
assembly
LEVER,PAPER FEED FRAME FIXING L,B
ASSEMBLY
1 F-5 679
Ribbon take-up gear assembly GEAR,RIBBON TAKE-UP ASSEMBLY 1 F-4 680
Carriage cover frame assembly FRAME,CARRIAGE COVER ASSEMBLY 1 F-2 681
screw(C.C.,3X5) C.C.SCREW,3X5,F/ZN 2 F-2 682
Nylon lock nut(M3) NYLON LOCK NUT M3 2 F-5 683
E-ring(1.5) RETAINING RING TYPE-E(1.5) 2 F-3 684
E-ring(2) RETAINING RING TYPE-E(2) F/UC 4 F-4 685
E-ring(3) RETAINING RING TYPE-E(3)F/UC 11 F-2,3,5 686
E-ring(4) RETAINING RING TYPE-E(4) F/UC 2 F-5 687
E-ring(5) RETAINING RING TYPE-E(5) F/UC 2 F-3,4 688
E-ring(2.3) RETAINING RING TYPE-E (2.3) F/UC 2 F-2,3 689
screw(C.C.S-tite,2.5X5) C.C.S-TITE SCREW,2.5*5,F/ZN 2 F-2,3 690
screw(C.B.S-tite F,3X6) C.B.S-TITEF,3X6,F/ZN 22 F-2,3,4 691
J/S change gear J/S CHANGE GEAR 1 F-2 692
Paper feed reduction gear PAPER FEED REDUCTION GEAR 1 F-2 693
Crank shaft holder CRANK SHAFT HOLDER 2 F-3 694
Paper feed trigger claw spring PAPER FEED TRIGGER CROW SPRING 3 2 F-3 695
Paper feed trigger attraction plate PAPER FEED TRIGGER ATTRACTIVE PLATE 2 F-3 696
Carriage motor MOTOR,CARRIAGE 1 F-4 697
Intermediate cable (type A) CABLE,INTERMEDIATE,A 1 F-4 698
Intermediate cable (type B) CABLE,INTERMEDIATE,B 1 F-4 699
Intermediate cable (type C) CABLE,INTERMEDIATE,C 1 F-4 700
Paper ejection detector cable assembly
(type A)
CABLE ASSEMBLY,PAPER EJECTION
DETECTOR,A
1 F-3 701
Paper ejection detector cable assembly
(type B)
CABLE ASSEMBLY,PAPER EJECTION
DETECTOR,B
1 F-2 702
R cover detector cable assembly CABLE ASSEMBLY,R COVER DETECTOR 1 F-3 703
Paper feed motor MOTOR,PAPER FEED 1 F-2 704
Lead wire (type A) LEAD WIRE,A 1 F-3 705
Lead wire (type B) LEAD WIRE,B 1 F-3 706
Lead wire (type C) LEAD WIRE,C 1 F-3 707
Lead wire (type D) LEAD WIRE,D 1 F-3 708
name for service manual name for price list Q’ty page Ref.#
