Appendix E-14 Parts List Rev. A
Confidential
Lead wire (type E) LEAD WIRE,E 1 F-3 709
Lead wire (type F) LEAD WIRE,F 1 F-3 710
Lead wire (type G) LEAD WIRE,G 1 F-3 711
Lead wire (type H) LEAD WIRE,H 1 F-3 712
Lead wire (type I) LEAD WIRE,I 1 F-3 713
Lead wire (type J) LEAD WIRE,J 1 F-3 714
Lead wire (type K) LEAD WIRE,K 1 F-3 715
Lead wire (type L) LEAD WIRE,L 1 F-4 716
Lead wire (type M) LEAD WIRE,M 1 F-4 717
Lead wire (type N) LEAD WIRE,N 1 F-4 718
Lead wire (type U) LEAD WIRE,U 1 F-2 719
Lead wire (type V) LEAD WIRE,V 1 F-2 720
Lead wire (type W) LEAD WIRE,W 1 F-2 721
screw(C.B.P-tite,3X8) C.B.P-TITE SCREW,3X8,F/ZN 1 F-3 722
Slip hold roller sleeve SLEEVE,SLIP HOLD ROLLER 1 F-2 723
Slip hold roller spring SPRING,SLIP HOLD ROLLER 1 F-2 724
Gear train cover COVER,GEAR TRAIN 1 F-4 725
Intermediate circuit board cover COVER,INTERMEDIATE CIRCUIT BOAD 1 F-4 726
Sub slip hold sleeve SLEEVE,SUB SLIP HOLD 2 F-3 727
Intermediate cable tube TUBE,CABLE INTERMEDIATE 1 F-4 728
screw(C.B.,2.6X4) C.B.,2.6X4,F/ZN 2 F-3 729
screw(C.B.S-tite F,3X4) C.B.S-TITE F,3X4,F/ZN 3 F-2 730
screw(C.P.S-tite(P4),3X6) C.P.S-TITE(P4),3X6,F/ZN 5 F-4 731
Connector plate (type BA) PLATE,CONNECTOR,BA 1 F-1 A
Parallel I/F circuit board assembly PARALLEL I/F CIRCUIT BOARD ASSEMBLY 1 F-1 B
screw(C.P.S-tite,3X6) C.P.S-TITE SCREW,3X6,F/ZN 2 F-1 C
name for service manual name for price list Q’ty page Ref.#
