Rev. A Parts List Appendix E-7
TM-H6000/H6000P Service Manual
Confidential
Slip paper guide PAPER GUIDE,SLIP 1 F-5 650
Slip T.O.F. detector assembly SLIP T.O.F. DETECTOR ASSEMBLY 1 F-3 671
Slip transmission gear GEAR,SLIP TRANSMISSION 3 F-2 638
Strengthening plate PLATE,STRENGTHEN,B 1 F-1 128
Sub slip feed lever shaft SHAFT,SUB SLIP FEED LEVER 1 F-3 636
Sub slip feed lever spring SPRING,SUB SLIP FEED LEVER 1 F-3 641
Sub slip feed lever sub assembly LEVER,SUB SLIP FEED SUB ASSEMBLY 1 F-3 660
Sub slip feed roller assembly ROLLER,SUB SLIP FEED ASSEMBLY 1 F-3 666
Sub slip feed roller holder HOLDER,SUB SLIP FEED ROLLER 1 F-3 644
Sub slip hold roller ROLLER,SUB SLIP HOLD 1 F-3 648
Sub slip hold sleeve SLEEVE,SUB SLIP HOLD 2 F-3 727
Support plate PLATE,SUPPORT,A 1 F-1 137
Switch panel cable CABLE,SWITCH PANEL 1 F-1 210
Switch panel circuit board assembly SWITCH PANEL CIRCUIT BOARD ASSEMBLY 1 F-1 208
Switch panel label LABEL,SWITCH PANEL 1 F-1 146
Switch panel unit SWITCH PANEL UNIT 1 F-1 124
Switch screw SCREW,SWITCH 1 F-6 549
Table holder HOLDER,TABLE 1 F-1 138
Thermal button BUTTON,THERMAL 2 F-1 134
Thermal case CASE,THERMAL 1 F-1 123
Thermal cushion CUSHION,THERMAL 2 F-1 130
Thermal frame FRAME,THERMAL 1 F-1 127
Thermal head FFC FFC,THERMAL HEAD 1 F-1 205
Thermal holder assembly HOLDER,THERMAL ASSEMBLY 1 F-1 125
Thermal mechanism assembly (M-H6000) THERMAL MECHANISM ASSEMBLY (M-
H6000)
1 F-1 500
Thermal mechanism cover COVER,THERMAL MECHANISM 1 F-1 135
Thermal print head assembly THERMAL PRINT HEAD ASSEMBLY 1 F-6 525
Thermal sheet SHEET,THERMAL 1 F-1 126
Thermal unit sensor circuit board assembly THERMAL UNIT SENSOR CIRCUIT BOARD
ASSEMBLY
1 F-1 204
Upper case CASE,UPPER 1 F-1 119
name for service manual name for price list Q’ty page Ref.#
