Appendix E-6 Parts List Rev. A
Confidential
Rubber insulator spacer SPACER,INSULATOR 2 F-1 113
Screening plate PLATE,SCREENING 1 F-6 536
screw(C.B.,2.6X4) C.B.,2.6X4,F/ZN 2 F-3 729
screw(C.B.,2X2.5) C.B.2X2.5,F/ZN 3 F-6 548
screw(C.B.B-tite,2X8) C.B.B-TITE,2X8,F/ZN 1 F-6 504
screw(C.B.B-tite,4X12) C.B.B.SCREW,4X12,F/ZN 2 F-1 108
screw(C.B.B-tite,4X25) C.B.B.SCREW,4X25 F/ZN 2 F-1 109
screw(C.B.P-tite,3X6) C.B.P-TITE SCREW,3X6,F/ZN 4 F-2,3 608
screw(C.B.P-tite,3X8) C.B.P-TITE SCREW,3X8,F/ZN 4 F-6 502
screw(C.B.P-tite,3X8) C.B.P-TITE SCREW,3X8,F/ZN 1 F-3 722
screw(C.B.S-tite F,3X4) C.B.S-TITE F,3X4,F/ZN 5 F-1 101
screw(C.B.S-tite F,3X4) C.B.S-TITE F,3X4,F/ZN 3 F-2 730
screw(C.B.S-tite F,3X6) C.B.S-TITEF,3X6,F/ZN 12 F-1 106
screw(C.B.S-tite F,3X6) C.B.S-TITEF,3X6,F/ZN 13 F-6 540
screw(C.B.S-tite F,3X6) C.B.S-TITEF,3X6,F/ZN 22 F-2,3,4 691
screw(C.C.,3X5) C.C.SCREW,3X5,F/ZN 2 F-2 682
screw(C.C.,4X20) C.C.SCREW,4X20,F/ZN 1 F-1 104
screw(C.C.S-tite,2.5X5) C.C.S-TITE SCREW,2.5*5,F/ZN 2 F-2,3 690
screw(C.C.S-tite,3X6) C.C.S.SCREW M3X6 3 F-1 105
screw(C.P.P-tite,3X12) C.P.P-TITE SCREW,3X12,F/ZN 1 F-4 607
screw(C.P.S-tite(0),3X6) C.P.S-TITE.(0),3X6,F/ZN 9 F-1,3 107
screw(C.P.S-tite(P4),3X6) C.P.S-TITE(P4),3X6,F/ZN 5 F-4 731
screw(C.P.S-tite,3X6) C.P.S-TITE SCREW,3X6,F/ZN 2 F-1 C
screw(C.P.T-B,3X10) C.P.T-B SCREW,3X10,F/ZN 7 F-1 103
Sensor circuit board assembly SENSOR CIRCUIT BOARD ASSEMBLY 1 F-6 541
Slip B.O.F. detector assembly SLIP B.O.F. DETECTOR ASSEMBLY 1 F-3 668
Slip drive gear GEAR,SLIP DRIVE 4 F-2,3,5 639
Slip feed roller ROLLER,SLIP FEED 1 F-5 649
Slip feed roller holder HOLDER,SLIP FEED ROLLER 1 F-5 643
Slip feed roller shaft holder SHAFT HOLDER,SLIP FEED ROLLER 4 F-2,3 609
Slip guide lower frame (type B) FRAME,SLIP GUID LOWER,B 1 F-3 646
Slip guide upper frame FRAME,SLIP GUID UPPER 1 F-3 645
Slip hold roller shaft SHAFT,SLIP HOLD ROLLER 1 F-2 637
Slip hold roller sleeve SLEEVE,SLIP HOLD ROLLER 1 F-2 723
Slip hold roller spring SPRING,SLIP HOLD ROLLER 1 F-2 724
Slip insertion detector holder HOLDER,SLIP INSERT DETECTOR 1 F-3 605
name for service manual name for price list Q’ty page Ref.#
To Next Page
