Rev. A Parts List Appendix E-5
TM-H6000/H6000P Service Manual
Confidential
Paper feed trigger attraction plate PAPER FEED TRIGGER ATTRACTIVE PLATE 2 F-3 696
Paper feed trigger claw spring PAPER FEED TRIGGER CROW SPRING 3 2 F-3 695
Paper holder PAPER HOLDER 1 F-6 526
Parallel I/F circuit board assembly PARALLEL I/F CIRCUIT BOARD ASSEMBLY 1 F-1 B
Plain washer(4.2X1X12) PLAIN WASHER,4.2X1X12,F/ZN 2 F-1 112
Platen adjustment screw SCREW,PLATEN ADJUSTMENT 2 F-5 658
Platen assembly PLATEN ASSEMBLY 1 F-6 511
Platen assembly PLATEN ASSEMBLY 1 F-5 678
Platen ground plate (type A) PLATE,PLATEN GROUND,A 1 F-5 651
Platen ground plate (type B) PLATE,PLATEN GROUND,B 1 F-5 652
Platen lever LEVER,PLATEN 1 F-5 623
Platen lever drive cam CAM,PLATEN LEVER DRIVE 1 F-2 626
Platen lever frame assembly FRAME,PLATEN LEVER ASSEMBLY 1 F-5 669
Platen lever shaft SHAFT,PLATEN LEVER,L 2 F-5 625
Platen lever spring SPRING,PLATEN LEVER 1 F-5 624
Platen shaft holder SHAFT HOLDER,PLATEN 1 F-6 503
Platen spring SPRING,PLATEN 2 F-5 603
Power switch cable assembly POWER SWITCH CABLE SET 1 F-1 207
Power switch cover COVER,POWER SWITCH 1 F-1 145
Press head spring SPRING,PRESS HEAD 2 F-6 506
Pressurizing plate PLATE,PRESSURIZING 1 F-6 519
Print head unit (Eb) PRINT HEAD UNIT EB 1 F-4 662
R cover detector cable assembly CABLE ASSEMBLY,R COVER DETECTOR 1 F-3 703
Receipt paper feed motor MOTOR,PAPER FEED,RECEIPT 1 F-6 544
Relaxation plate PLATE,RELAXATION 1 F-6 520
Relaxation plate fixing plate PLATE,RELAXATION PLATE FIXING 1 F-6 547
Ribbon cassette cover COVER,RIBBON CASSETTE 1 F-1 121
Ribbon drive plate assembly RIBBON DRIVE PLATE ASSEMBLY 1 F-4 674
Ribbon feed spring RIBBON FEED SPRING 1 F-4 601
Ribbon intermediate gear GEAR,RIBBON INTERMEDIATE 1 F-4 657
Ribbon reduction gear GEAR,RIBBON REDUCTION 1 F-4 656
Ribbon take-up gear assembly GEAR,RIBBON TAKE-UP ASSEMBLY 1 F-4 680
Right frame FRAME,RIGHT 1 F-6 514
Right thermal spring SPRING,THERMAL,R 1 F-1 132
RS-232 I/F circuit board assembly RS-232 I/F CIRCUIT BOARD ASSEMBLY 1 F-1 202
Rubber foot RUBBER FOOT 3 F-1 117
name for service manual name for price list Q’ty page Ref.#
To Next Page
