Erbe VIO 200 D - Fingerswitch Activation

10 • Maintenance and servicing
102 / 144
Art.-Nr.: 80116-271 04.06
Dual-pedal footswitch
ReMode
1. Press ReMode button on the dual-pedal footswitch. The test pro-
gram must confirm switchover by lighting up the relevant field in
color in the "MF" icon.
Fingerswitch activation
Testing and measuring equipment
Test set-up
Fig. 10-3
• The test specimen is connected to the power supply via the power
cord.
• The test program "TP activation signal" is selected.
ERBE
Art.-Nr.
Bezeichnung
20192-127
20192-110
Patientenkabel AE
oder
Patientenkabel AE, international
20190-045 Elektrodengriff ICC/ACC
20190-115 VIO ReMode Elektrodengriff
(only if there is an MF receptacle)
