19 / 144
4 • Technical Data
Art.-Nr.: 80116-271
04.06
CHAPTER 4
Technical Data
Power connection
Rated supply voltage 100 V - 120 V ± 10% / 220 V - 240 V ± 10%
Rated supply frequency 50 / 60 Hz
Line current 8 A / 4 A
Power input in standby mode 40 watts
Power input with max. HF output 500 watts / 920 VA
Terminal for potential equalization yes
Power fuses T 8 A / T 4 A
Operating mode
Intermittent operation ON time 25% (e.g. activated for 10 sec. / deacti-
vated for 30 sec.)
Dimensions and weight
Width x height x depth 410 x 165 x 380 mm
Weight 9.5 kg
Ambient conditions for transport and storage of unit
Temperature -40 °C to + 70 °C
Relative humidity 10% - 95%
Ambient conditions for operation of unit
Temperature +10 °C to + 40 °C
Relative humidity 15% - 80%, noncondensing
