Erbe VIO 200 D - Rear Panel Controls

3 • Controls
16 / 144
Art.-Nr.: 80116-271 04.06
Controls at the rear
VIO D with screw-in power supply module
Fig. 3-2
IMPORTANT! This unit comes with different power supply modules – plug-in or
screw-in.
1 Footswitch sockets
2 ECB socket (ERBE Communication Bus)
3 Potential equalization terminal
4 Power supply module with fuses
