11 / 144
2 • Modifications
Art.-Nr.: 80116-271
04.06
CHAPTER 2
Modifications
As from VIO version 1.3.x
Hardware
Software
Component affected Description of the modification
APC 2 module In addition to the APC receptacle, another receptacle can be
added. The second receptacle can be either a multifunctional
(only in conjunction with a VIO 300 D), monopolar or bipolar
receptacle.
IES 2 module The IES 2 smoke evacuation system can be attached to the
VIO HF surgical unit and operated via said unit.
Component affected Description of the modification
VIO module New modes:
DRY CUT ° (only relevant for VIO 300 D)
SWIFT COAG ° (only relevant for VIO 300 D)
SET-UP settings Power Display:
When the unit is restarted, the power
display is always deactivated (=OFF).
Neutral electrode:
Additional option “dynamic”.
New SET-UP settings:
Display time
APC Purge Flow/APC purging flow
DRY °/SWIFT ° (only relevant for VIO 300 D)
Additions to test programs:
Error list IIF/NE
Hardware TP
Upgrade list
