103 / 144
10 • Maintenance and servicing
Art.-Nr.: 80116-271
04.06
Test procedure
20190-045
Activation CUT / COAG
1. Connect the electrode handle with patient cable AE to the Mono-
polar receptacle of the test specimen.
2. Press CUT button on the electrode handle. The test program
must confirm activation by lighting up the relevant field in color in
the "Handpiece" icon.
3. Press COAG button on the electrode handle. The test program
must confirm activation by lighting up the relevant field in color in
the "Handpiece" icon.
4. Remove the electrode handle.
20190-115
Activation CUT / COAG
(only if there is an MF
receptacle)
1. Connect the VIO ReMode electrode handle to the MF receptacle
of the test specimen.
2. Press CUT button on the VIO ReMode electrode handle. The
test program must confirm activation by lighting up the relevant
field in color in the "Handpiece" icon.
3. Press COAG button on the VIO ReMode electrode handle. The
test program must confirm activation by lighting up the relevant
field in color in the "Handpiece" icon.
20190-115
ReMode
(only if there is an
MF receptacle)
1. Press ReMode button on the electrode handle. The test program
must confirm switchover by lighting up the relevant field in color
in the "Handpiece" icon.
2. Remove the VIO ReMode electrode handle.
Instrument recognition MF receptacle
Testing and measuring equipment
Instrument recognition via
resistance
Currently not available.
Instrument recognition via
EEPROM
Test set-up
• The test specimen is connected to the power supply via the power
cord.
Test procedure
1. Connect BiClamp measuring cable to the MF receptacle of the
test specimen. The test specimen must indicate instrument
recognition with a message. The setting for COAG mode must
change to BiClamp.
ERBE
Art. No.
Description
20100-152 BiClamp measuring cable
