Erbe VIO 200 D - Circuit Boards

141 / 144
11 • Spare parts
Art.-Nr.: 80116-271 04.06
Circuit Boards
Fig. 11-17
Motherboard
30140-811
Power supply
30140-810
HF generator module
30140-804 up to version 1.4.x 30140-828 as from version 1.5.x
NESSY2 30140-813
IIF ** IIF **
CPU + Sensors *
CAN-HF 30140-812
J2
1
1
1211
2
J18
1
12 11
2
Low voltage power supply 30140-817
**
IIF ME 30134-800 IIF BE 30140-814 IIF MF 30140-815
only relevant for VIO 300 D
MP3
AE
NE
+
-
GND GND -15V +15V
+24V
+5V +5V
Powerfail
+24V +15V
-15V
+5V GND GND
J20 J21
J28
J26
J19
J25
* not pre-balanced 30140-809
pre-balanced 30140-824
J20, Low voltage power supply J19, J21
J26, J28 J25, J44
J44
