47 / 144
7 • Test programs
Art.-Nr.: 80116-271
04.06
Output receptacle Select active receptacle (1...3) and its configuration (monopolar or bi-
polar). With the setting "No receptacle" the HF voltage is only present
at the throughplating on the floor of the housing.
Generator The generator can be switched on with any available activation ele-
ment:
• fingerswitch at monopolar receptacle (yellow or blue)
• fingerswitch at APC receptacle (yellow or blue)
• dual-pedal footswitch (yellow or blue)
• single-pedal footswitch
Measurement values
Settings Test modes
U DC: output voltage of high-voltage power supply unit
I DC: output current of high-voltage power supply unit
UpHF: peak value (pos.) of HF voltage
IpHF: peak value of HF current
Phase: phase angle (0...90°)
Spark: value measured by spark sensor
(no spark = 44 ERBE)
UHF red.: value measured by redundant voltage sensor
Tem p. : Inside temperature of unit
(measured on “CPU + Sensors” circuit board)
SOFT AUTO FORC. SPRAY
Setting range of
power supply unit
voltage
0...250 V 0...250 V 0...450 V 0...450 V
Current limitation
power supply unit
3.5 A 3.5 A 1.75 A 1.75 A
Power supply unit
range
250 V / 450 V
Rel
13
250 250 450 450
Switching transis-
tors
250 V / 500 V
Rel
43
250 250 500 500
Transformer tap
Rel
35 (1 : 4)
Rel
37 (1 : 5.5)
Rel
39 (1 : 11)
1 : 4 1 : 4 1 : 5.5 1 : 11
Attenuation
Rel
41
no no yes yes
