SMART-2 Multi Functional Wireless Weighing Indicator User Manual
________________________________________________________________________________________________
Page 27
RELAY 1 SET HYSTERESIS SETTING
Hysteresis can be expressed as the difference between the opening and closing
values of the relay or the amount return loss.
(1) Press key until you reach the 'Relay 1'
menu
(2) Press the key to confirm the menu
(3) Press key until you reach the 'Relay 1
hysteresis' menu
(4) Press the key to confirm the menu
(5) The last recorded relay 1 hysteresis value will
be displayed on the screen and the hundreds
digit blinks at the same time
(6) Numeric value of the blinking digit can be increased with key. The
place value can be changes with key.
(7) Press the key to save relay 1 hysteresis value.
(8) Press the key to go back to the measurement screen.
NOTE: Hysteresis quantity can be between 0 and 255.
