Corrective Maintenance
Fox Maintenance © Essemtec AG 5-13
0000074/05
/ March 31,
2017
Clean the groove and the four vacuum holes
with the conical brush SP26/MAIN 02.
Take the special grease for P&P Head SP26/HG04
and shake it well before using. By means of the
integrated brush apply a tiny amount of grease
above the groove. Turn the axis while applying.
Move the feedthrough piece to the uppermost
position.
Make sure that the metal pin fits into the hole of
the bearing.
