(1) Technical parameters:
Battery type FG12150 FG12200
Voltage 12 V 12 V
Design service life 3 – 5 years 3 – 5 years
Maximum discharging current (25 °C) 225 A (5 s) (25 °C) 300 A (5 s)
Kind of charging
Range
Max. charging current
Constant voltage (25 °C)
14,5 – 14,9 V
6 A
Constant voltage (25 °C)
14,5 – 14,9 V
8 A
Operating temperatures
Charging
Discharging
Storage
-20 – 60 °C
-10 – 60 °C
-20 – 60 °C
-20 – 60 °C
-10 – 60 °C
-20 – 60 °C
Weight 4,75 kg 5,9 kg
Battery discharging (hours)
Current (A)
Voltage (V)
Capacity (Ah)
FG12150
20 0,75 10,5 15
10 1,4 10,5 14
5 2,5 10,5 12,5
1 10,3 9,6 10,3
FG12200
20 1,0 10,5 20
10 1,85 10,5 18,5
5 3,45 10,5 17,25
1 13,4 9,6 13,4
Table 24-1 Battery discharging
G. Battery SV-BAT-320
The standby battery SV-BAT-320 serves for feeding the Dynon SkyView system in the case of
an on-board network failure. It doesn´t require any maintenance in the operation, the battery is
tested once a year only. After the test, the system itself evaluates whether it is still possible to
use the battery in the operation. Replace the battery in the case when the test result is negative.
H. Battery IBBS-12v-3ah
The standby battery IBBS-12v-3ah serves for feeding the Garmin G3X system in the case of an
on-board network failure. It doesn´t require any maintenance in the operation, the battery is
tested once a year only. Replace the battery in the case when the test result is negative.
