Evector SportStar RTC - Maintenance Practices; Air System of Engine

ERTC022-10-AS
MAINTENANCE MANUAL
71-60
Page 71-22
2017-12-22
Effectivity: All
Edition 2 | Rev. 0
2. MAINTENANCE PRACTICES
A. Air system of engine
Maintenance type: Line
Personnel qualification: Independent verification personnel qualified in accordance with
Part 66 or higher
Recommended tools and material:
Item
Designation / Size
Quantity
Note
Phillips screwdriver No. 2 1 pc.
Air filter ROTAX P/N
825 750
1 pc.
Wrench No. 7 1 pc.
Wrench No. 8 1 pc.
Wrench No. 10 1 pc.
Hex key No. 5 1 pc.
Flat screwdriver - 1 pc.
(1) Servicing – air filter replacement
(a) Switch the electrical network off and disconnect the battery.
(b) Remove the engine cowlings (Section 71-10).
(c) Release the sleeve (5, Fig. 71–6) and take out the filter (1).
(d) Set the new filter (1) to position to the filter bracket (2) and install the sleeve (5).
(e) Install the engine cowlings (Section 71-10).
(f) Connect the battery, switch the electrical network on.
