MAINTENANCE MANUAL
Page 33-12
Effectivity: All
Edition 2 | Rev. 0
2. MAINTENANCE PRACTICES
A. 90340 series positon / strobe lights
Maintenance type: Line
Personnel qualification: Independent verification personnel qualified in accordance with
Part 66 or higher
Recommended tools and material:
Philips screwdriver No. 2 1 pc.
Flat screwdriver - 1 pc.
Pincers - 1 pc.
Soldering iron - 1 pc.
Solder - -
Heat gun - 1 pc.
Shrinkable tube ø 3x1 mm -
Cleaning agent Technical benzine -
Sealant Transparent sanitary
silicone
-
Lint free cloth - -
NOTE
The removal / installation procedures for left and right lights are
identical.
(1) Removal – flashtube of the strobe light
WARNING
THE STROBE LIGHTS ARE HIGH-VOLTAGE DEVICE. DO
NOT REMOVE OR TOUCH THE FLASHTUBE DURING
OPERATION. AFTER YOU SWITCH THE SYSTEM OFF,
WAIT 5 MINUTES, BEFORE YOU START THE WORK.
(a) Switch the electrical network off and disconnect the battery.
(b) Remove the cover W4L or W4R (Fig. 06-2).
(c) Disconnect the connector with wires (13, Fig. 33-5) from the harness.
(d) Unscrew the screws (9) and remove the flashtube cover (2) including the lens (4).
To Next Page
