MAINTENANCE MANUAL
Effectivity: All
Page 33-25
Edition 2 | Rev. 1
Fig. 33-9 Adjustment of the landing and taxi light
E. 7114112 taxi light
Maintenance type: Line
Personnel qualification: Independent verification personnel qualified in accordance with
Part 66 or higher
Recommended tools and material:
Item Designation / Size Quantity Note
Test jig 7810E2550001 1 pc. Light adjustment
Jig with magnifier 7910S7911099 1 pc. Light adjustment
Flat screwdriver - 1 pc.
Phillips screwdriver No. 2 1 pc.
Wrench No. 7 1 pc.
Wrench No. 10 2 pc.
Hex wrench No. 3 1 pc.
Crimping pliers - 1 pc.
Pincers - 1 pc.
Connector P/N 1-480319-0 1 pc.
Contact P/N 163305-2 2 pcs.
