Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
Page - 84 Revision 2.2 MASTER CLOCK
OUTPUT
(continued)
ATG 1 (1, 2)
(continued)
Time zone
0:00 hours
DST Ctl
Off
On
Syncro
Include syncro
Exclude syncro
Analog Audio
Left frequency
20Hz – 12.0kHz
Right frequency
20Hz – 12.0kHz
Left level [LIVE]
Audio Level
Left 10.0 dBu
Right 10.0 dBu
Right level [LIVE]
Audio Mode
Steady tones
Timed tones
Audio Event 1
Audio Event 2
Audio Event 3
Audio Event 4
Audio Event 5
Audio Event 6
Audio Event 7
Audio Event 8
Audio Event 9
Audio Event 10
Set Event Time
Set Event Time
0:00:00.00
every minute
every hour
Audio type
mute
constant left
constant right
constant both
beep left
beep right
beep both
bell left
bell right
bell both
beep l const r
beep r const l
bell l const r
bell r const l
Left Frequency
20Hz – 12.0kHz
Right Frequency
20Hz – 12.0kHz
Duration
0.1 Seconds.
Test event [LIVE]
BEEP TEST
AES Audio
AES/DARS/WC lck
PAL/integer
NTSC/fractional
AES coarse [LIVE]
AES/DARS/WC
Phasing
coarse fine
0 0
AES fine [LIVE]
WC phase [LIVE]
Wordclock
Phasing
0
AES1 Left Freq
20Hz – 12.0kHz
AES1 Left level
0 dBFS to -30 dBFS
AES1 Right Freq
20Hz – 12.0kHz
AES1 Right levl
0 dBFS to -30 dBFS
AES2 Left Freq
20Hz – 12.0kHz
AES2 Left level
0 dBFS to -30 dBFS
AES2 Right Freq
20Hz – 12.0kHz
AES2 Right levl
0 dBFS to -30 dBFS
Global Pedestal
Pedestal Off
Pedestal On
