evertz 5601MSC - Page 99

Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 83
OUTPUT
(continued)
SDI TG 1 (1, 2, 3, 4)
(continued)
Jam Output Jam Output [LIVE]
TIME JAMMED
Jam all VITC/LTC Jam all VITC/LTC [LIVE]
ALL TIMES JAMMED
Time offset
0 frames
Time zone
0:00 hours
DST Ctl
Off
On
Output Drive
Auto detect ACO
No 5601ACO2
5601ACO2 in use
Syncro
Include syncro
Exclude syncro
ATG 1 (1, 2)
Signal
BLACK
GREY
WHITE
FIELD ID (B=1, W=2)
10 Y STEP
Y RAMP
SHALLOW Y RAMP
MODULATED RAMP
CCIR 17
CCIR 18
CCIR 330
2T 3T 20T PULSE AND BAR
100% Y SWEEP
60% Y SWEEP
75% COLOR BARS
100% COLOR BARS
SMPTE BARS
NTC7 COMPOSITE
NTC7 COMBINATION
FCC COMPOSITE
FCC MULTIBURST
60% EXTENDED MB
Y MULTIPULSE
2T PULSE & BAR
SIN(X)/X
COMPOSITE SIGNAL
Image Format
525 NTSC M
625 PAL B
Fine phase [LIVE]
Phase value
cf v h fine%
1 1 1 0.0
Hor phase [LIVE]
Vert phase [LIVE]
Color phase [LIVE]
Message Ctl
Message Off
Message 1 line
Message 2 lines
H position [LIVE]
Message Position
vert. hor.
2 1
V position [LIVE]
Message 1
EVERTZ 5601MSC
Message 2
Master Sync
Message font
Normal size
Large size
TC Burn in
Off
On
Dropframe Ctl
Off
On
Color Frame
Set Jam Time
0:00
Jam Output Jam Output [LIVE]
TIME JAMMED
Jam all VITC/LTC Jam all VITC/LTC [LIVE]
ALL TIMES JAMMED
Time offset
0 frames
