Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
Page - 80 Revision 2.2 MASTER CLOCK
Level 1 Level 2 Level 3 Level 4 Level 5
OUTPUT
LTC 1 & LTC 2
or
LTC/IRIG 1 and
LTC/IRIG 2
Power Applied
(LTC 1 Only)
Power Off
Power On
Frame Rate/Irig
23.98 FPS
24 FPS
25 FPS
29.97 FPS
29.97DF FPS
30 FPS
IRIG
Set Jam Time
0:00
Jam Output Jam Output [LIVE]
TIME JAMMED
Jam all VITC/LTC Jam all VITC/LTC [LIVE]
ALL TIMES JAMMED
Time offset
0 frames
Time zone
0:00 hours
DST Ctl
Off
On
Output Level
level = 7
Parity
Parity Off
Parity On
Color Frame
Color Frame Off
Color Frame On
Irig mode
B122
B123
B124
B127
Irig offset [LIVE]
0 seconds
SYNC 1 (1, 2, 3, 4, 5, 6)
Or
10 MHz
Or
Wordclock
Mode
PAL-B
NTSC-M
1080i/50
1080i/59.94
1080i/60
1080p/23.98
1080p/23.98sF
1080p/24
1080p/24sF
1080p/25
1080p/29.97
1080p/30
1080p/50
1080p/59.94
1080p/60
720p/24
720p/30
720p/50
720p/59.94
720p/60
625i/48
625i/47.95
480p/59.94
576p/50
PAL color frame
1 Hz
1/1.001 Hz
6/1.001 Hz
IRIG datum
5 MHz
10 MHz
NTSC-M subcarr.
PAL-B subcarr.
Wordclock
Vitc Ctl
Off
On
