evertz 5601MSC - 4.4. CONFIGURING THE OUTPUTS

Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 81
OUTPUT
(continued)
SYNC OUTPUTS
(continued)
Vitc Line 1
line 1 = 14
Vitc Line 2
line 2 = 16
Dropframe Ctl
Off
On
Color Frame
Color Frame Off
Color Frame On
Set Jam Time
0:00
Jam Output Jam Output [LIVE]
TIME JAMMED
Jam all VITC/LTC Jam all VITC/LTC [LIVE]
ALL TIMES JAMMED
Time offset
0 frames
Time zone
0:00 hours
DST Ctl
Off
On
Ten field Ctl
Off
On
Fine phase [LIVE]
Phase value
Cf v h fine%
0 0 0 0.0
Hor phase [LIVE]
Vert phase [LIVE]
Color phase [LIVE]
Pulse type
5V CMOS
+/-1V bi-level
+/-1V tri-level
Sine wave level
+/-1 Volts
+/-2 Volts
Wordclock levl
5V CMOS
+/-1 Volts
SDI TG 1 (1, 2, 3, 4)
Signal
BLACK
WHITE
FIELD IDENT. (B=1, W=2)
FRAME IDENT.
100% COLORBARS
75% COLORBARS
75% BARS W. 100% WHITE
RP219 COLORBARS
LAB BARS, MOVING BOX
VALID RAMP
100% WHITE WINDOW
50% WHITE WINDOW
20% WHITE WINDOW
SDI CHECKFIELD
GREY (QUIET)
GREY (ALL BITS ACTIVE)
FULL FIELD PLUGE
10 FRAME SEQUENCE
BOUNCING BOX
30Fps 4 FILM FRAME SEQ.
1s & 5s IDENT. W. AUDIO
60% Y LINE SWEEP 30MHZ
MULTIPULSE
Y MULTIPULSE
CIRCLE WITH CENTER CROSS
CLEAN APERTURE WITH GRAT
Format Interface
Single Link HD
3G Level A
3G Level B
Dual Link HD
Standard Def
