FAAC 746 C User Manual

6
746 C - 844 C 14 532150 - Rev.A
1
2
3
1
9
4
5
6
7
8
Translation of the original instructions
ENGLISH
2.11 EXAMPLE SYSTEM
The example is an illustration only and is just one of the possible applications.
1 Mains power supply 3G 1.5 mm (max 2.5 mm)
2 Circuit breaker and differential switch
3 Junction box
4 Gearmotor
5 Photocell TX
6 Photocell RX
7 Key button
8 Flashing light
9 Mechanical stop
