746 C - 844 C 39 532150 - Rev.A
Translation of the original instructions
ENGLISH
8.3 STOP / SAFETY STOP
The command stops the automation.
Make the connections and programming indicated
in the table for functional STOP or safety STOP (e.g.
on the pedestrian door integrated in the sliding leaf).
FAILSAFE
failsafe is a functional test that is carried out when the
contact is opened. If the test fails, the board generates
an error and prevents the automation from moving.
INPUTS ADVANCED PROGRAMMING
STOP device with NC contact
active in all states
5 STOP
6/7/8 (–)
2F = 00
Safety STOP device with NC contact
active in all states
5 STOP
11 OUT1 / 12 OUT2
2F= 01 Failsafe test on STOP input
o1/ o2 = 01 (Failsafe)
