FAAC 746 C User Manual

746 C - 844 C 10 532150 - Rev.A
Translation of the original instructions
ENGLISH
TECHNICAL DATA
746 C Z16
data referring to 230 V~ @50 Hz
746 C Z20
data referring to 230 V~ @50 Hz
Power supply voltage 220 - 240 V~ @50/60 Hz 220 - 240 V~ @50/60 Hz
Max power 300 W 300 W
Pinion Z16 Module 4 Z20 Module 4
Max torque at initial thrust 466 N 372 N
Max thrust force 830 N 665 N
Max leaf weight 600 kg 400 kg
Max leaf speed 9.6 m/min 12 m/min
Max leaf length 40 m 50 m
Stopping space 30 mm 30 mm
Type of use Industrial/Commercial/Residential Industrial/Commercial/Residential
Use frequency Continuous use Continuous use
Protection rating IP44 IP44
Ambient operating temperature -20°C - +55°C -20°C - +55°C
Thrust capacitor 12.5 µF 12.5 µF
Thermal protection 120°C automatic rearming 120°C automatic rearming
Gearmotor weight 16.2 kg 16.5 kg
Oil supplied by FAAC supplied by FAAC
844 C Z16
data referring to 230 V~ @50 Hz
844 C Z16 115V
data referring to 115 V~ @60 Hz
Power supply voltage 220 - 240 V~ @50/60 Hz 110 - 120 V~ @50/60 Hz
Max power 500 W 800 W
Pinion Z16 Module 4 Z16 Module 4
Max torque at initial thrust 606 N 619 N
Max thrust force 1300 N 1275 N
Max leaf weight 1800 kg 1800 kg
Max leaf speed 9.6 m/min 11.7 m/min
Max leaf length 40 m 40 m
Stopping space 30 mm 30 mm
Type of use Industrial/Commercial/Residential Industrial/Commercial/Residential
Use frequency Continuous use Continuous use
Protection rating IP44 IP44
Ambient operating temperature -20°C - +55°C -20°C - +55°C
Thrust capacitor 18 µF 70 µF
Thermal protection 120°C automatic rearming 120°C automatic rearming
Gearmotor weight 16.9 kg 16.9 kg
Oil supplied by FAAC supplied by FAAC

FAAC 746 C Specifications

General

Brand	FAAC
Model	746 C
Category	Garage Door Opener
Language	English
