746 C - 844 C 2 532150 - Rev.A
Translation of the original instructions
ENGLISH
1. INTRODUCTION TO THE INSTRUCTION MANUAL
SAFETY WARNINGS FOR THE INSTALLER
Before starting the installation, read and comply with
the “Safety warnings for the installer” booklet supplied
with the product, and these installation instructions.
MEANING OF THE SYMBOLS USED
NOTES AND WARNINGS ON THE INSTRUCTIONS
i
WARNING - Details and specifications which must be
respected in order to ensure that the system operates
correctly.
RECYCLING AND DISPOSAL - The materials used in manu-
facturing, the batteries and any electronic components
must not be sent to landfill. They must be taken to
authorised recycling and disposal centres.
FIGURE E.g.: 1-3 see Figure 1 - item 3.
TABLE E.g.: 1 see Table 1.
§
CHAPTER/SECTION E.g. § 1.1 see section 1.1.
TABLES
1 Basic programming menu ...........................31
2 Advanced programming menu ......................32
3 Assigning an address to Bus 2Easy photocells .........40
4 Addressing Bus 2Easy sensitive edges ................41
5 Addressing Bus 2Easy control devices ................41
6 Errors, Alarms ......................................48
7 Scheduled maintenance ............................50
APPENDICES
1 Foundation for leaves of maximum weight and width . 57
This manual provides the correct procedures and
requirements for installing 746 C - 844 C and main-
taining it in a safe condition.
In Europe, the automation of a gate falls under the Ma-
chinery Directive 2006/42/EC and the corresponding
harmonised standards. Anyone automating a gate
(new or existing) is classified as the Manufacturer of the
Machine. They are therefore required by law, among
other things, to carry out a risk analysis of the machine
(automatic gate in its entirety) and take protective
measures to fulfil the essential safety requirements
specified in Annex I of the Machinery Directive.
FAAC S.p.A. recommends that you always comply
with the EN 12453 standard and in particular that you
adopt the safety criteria and devices indicated, without
exception, including the dead-man function.
This manual contains references to European stan-
dards. The automation of a gate must fully comply
with any laws, standards and regulations applicable in
the country where installation will take place.
i
Unless otherwise specified, the measurements provided
in the instructions are in mm.
Displaying Error Codes, Alarms ........................ 48
11. MAINTENANCE ...................................... 50
11.1 Scheduled maintenance .............................. 50
11.2 Restore factory settings............................... 52
11.3 Programming the schedule maintenance request ....... 52
11.4 Cycle counter ........................................ 52
12. UPDATING THE BOARD FIRMWARE .................53
12.1 UPGRADE - Load the new FW ......................... 53
12.2 DOWNGRADE - Load a previous FW version ............. 53
13. INSTRUCTIONS FOR USE ............................54
Commands ........................................... 54
Detection devices ..................................... 54
Accessories ........................................... 54
Operating logics ...................................... 54
13.1 Emergency use ....................................... 56
13.2 Manual operation .................................... 56
Releasing the gearmotor .............................. 56
Restoring operation .................................. 56
