Direct Outputs
Overview
Direct Output levels are controlled in the Path display.
This guide shows you how to configure the physical I/O for Direct Outputs.
Get Ready
Press the green Setup button.
Select the path whose inserts you wish to configure. Press the
Direct Config button.
Operation
Before you can work on a Direct Output, it must be given a physical output. To do this, press the
Patch Outputs soft key. Click Analog Outputs or Digital Outputs, choose an output, click
Patch. Operation is the same as How To Recording Patch Inputs
Press the
Patch Outputs soft key again to exit.
To change the gain of the Direct Output, press the gain soft key. Use the
Jog Wheel to change
the displayed number. This will be expressed as REL (relative) if more than one output is active
i.e. when a Link Group is selected. Press
Enter to apply.
The
ON/OFF toggle and the PRE/POST toggle are available once the output is defined.
Oscillator
The system oscillator is toggled on and off in the Mixer or Record Megamode, using the osc
button.
To set Oscillator frequency and level, use
Utils in the Setup Megamode.
To route the Oscillator to a bus, first
patch it to Talkback 2 on the Patch Screen (press patch in
the Mixer or Record Megamode), then connect Talkback 2 to the desired bus as follows:
Hold down BLUE and press
Talk
Select the
Bus(es) to be destinations for Talkback 2.
Press
Exit.
Noise Generator
The system noise generator is toggled on and off in the Mixer or Record Megamode, using the
osc button.
Patching the noise generator to any point in the system is done using the Patch page, in the same
way as for the oscillator.
Using Faders
Overview
Xynergi supports two types of external faders.
1. Fairlight Fader Side Car (12 faders). Xynergi will support up to two of these.
2. Mackie Control Extender Pro (8 faders). Xynergi will support one of these systems.
