Fargo DTC300 - Installing the Flipper Table Module Assembly (D900200) (Continued)

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC300/DTC300M Card Printer/Encoder User Guide (Rev. 2.2)
3-16
Installing the Flipper Table Module Assembly (D900200) (continued)
Step Description
3 Remove the Card Output or Exit Door (D900092) and Left End Cap (D900064)
to the Printer, as shown below.
