Reviewing the DTC400 Sequence of Operations
Step
Process
16 The Image data is burned by the Printhead until image data is depleted. All Stop.
17 The Thermistor engages Printhead Cooling Fan to maintain proper operating
temperature.
18 The Headlift Motor engages.
19 The Print Headlift Sensor detects an open state.
20 The Print Headlift Motor disengages.
21 The Print Stepper Motor engages.
22 The Print Ribbon Drive engages.
23 The Card Feed Stepper Motor engages to queue card for magnetic encoding.
24 The Encoding data is written to the card.
25 The Card Feed Stepper will re-queue card for each verification pass required.
26 After Ribbon advances a few encoder clicks, assume Ribbon free of card. All
Stop.
27 Repeat steps 9 through 23 for appropriate number of color/overlay panels.
28 The Card is ejected from the singled-sided Printer.
OR
The Card Feed Stepper engages to queue the card for the Flipper Table for the
dual-sided Printer.
29 All Stop.
To Next Page
