RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

6-89

Reviewing the Ribbon Information

Step Procedure

1 Use the Ribbon information to determine which Ribbon is being used to print with

and its part number.
