DTC400 Card Printer/Encoder User Guide (Rev. 2.2)
6-87
Selecting the Print YMC under K and Print K Only options
Step Procedure
1
 Select between the Print YMC Under K and Print K Only options. (Note:
When the Print YMC Under K option is selected, all black in the designated
areas will print with the Yellow (Y), Magenta (M) and Cyan (C) Ribbon panels
directly beneath the resin black (K) panel.)
OR
 Select this option if printing resin black text or bar codes onto a colored
background to provide a more gradual transition between the two.
2
Select the Print K Only option if printing resin black onto a white background to
maximize the sharpness of printed text and bar codes. (Note: When this option
is selected, all black in the designated areas will print only with the resin black
(K) panel.)

Fargo DTC400 Specifications

General

Print Resolution	300 dpi
Connectivity	Ethernet (optional)
Dimensions	254 x 254 x 229 mm (10 x 10 x 9 in)
Weight	6.8 kg (15 lbs)
Print Technology	Dye-Sublimation / Resin Thermal Transfer
Card Capacity	100 cards (input hopper)
Card Sizes Accepted	CR80 (3.375" x 2.125")
Card Thickness	0.76 mm (30 mil)
Memory	32 MB RAM
Operating System Supported	Windows
Operating System Compatibility	Windows 7, 8, 10 (32-bit and 64-bit)
Print Area	Full bleed
