RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

11-7

Downloading Firmware (continued)

Step Procedure

Click on the Printer name under Printer Firmware to begin the download, as

shown below.
