Laser Scanner Manual
149
Chapter 10: Technical Data
10.3 Data handling and control
10.4 Ranging unit
Focus
S
Plus
Data storage: SD cards of type SDHC™ and SDXC™;
32 GB card included
Scanner control: Through touchscreen display and WLAN
connection. Access by mobile devices
through HTML5.
Distance Accuracy: 1 mm
Angular Accuracy: Horizontal: 19 arcsec
Vertical: 19 arcsec
Unambiguity interval: 614 m for up to 0.5 Mio. pts/s;
307 m at 1 Mio. pts/s;
153 m at 2 Mio. pts/s
Range Focus
S
Plus 150:
0.6 m to 150 m indoor or outdoor with upright
incidence to a 10% reflective surface
Range Focus
S
Plus 350:
0.6 m to 350 m indoor or outdoor with upright
incidence to a 10% reflective surface
Measurement speed (pts/sec): up to two million
Ranging error
1
Focus
S
:
±1 mm
Ranging noise
2
@10 m @25 m
@ 90% refl. 0.1 mm 0.2 mm
@ 10% refl. 0.3 mm 0.5 mm
