Chapter 6: Getting Started
The Reset Zoom button is only visible when you zoom into the scan
picture. With this button the scan picture can be zoomed back to its original
size.
When zoomed in you can move the zoomed picture by dragging it with your
fingers in any direction.
The Inclination in degrees is displayed in the header bar
The following inclination warning message is displayed if the current
inclination of the scanner is above 5°.
Strong scanner inclination
Inclination of the scanner is not within +/- 5°. This could result in slightly
inexact scan measurements.
Try to position the scanner so that its inclination is between +/-5°.To get
reliable measurements from the built-in dual axis compensator you should set
up the scanner with an inclination less than 5° before starting your next scan.
For this, you may use either a bubble inclinometer at the tripod or the
inclinometer screen. Tap this button to get to the inclinometer screen.
6.9 LED Behavior
Scanner Status LED at Power ON/OFF button
Scanner off, external power supply not
connected
off
Regular boot process flashes blue and fast
Battery operation constantly blue
Power On/Off flashes blue
Scanner Status LED next to the battery
Scanner off, external power supply not
connected
off
Regular boot process flashes blue and fast
Battery operation constantly blue
Low battery operation at battery state
less than 10%
flashes blue
Low battery operation at battery state
less than 5%
flashes violet
AC adapter operation only (no battery) green
