Faro Focus M 70 - Front Side; Bottom Side

FARO
®
Laser Scanner Manual
24
Chapter 5: Parts and their Functions
5.1.3 Front Side
Figure 5-3: Front View of the FARO Laser Scanner
 Scanner mirror - for safety and cleaning instructions see Mechanical Safety
on page 19 and
Cleaning Instructions for Optics on page 135.
 Scanner mount
 Reference area - used for self-referencing the distance measurements
while scanning
5.1.4 Bottom Side
Figure 5-4: Bottom View of the FARO Laser Scanner
 3/8” screw thread to mount the scanner to standard photo tripods.
 M5 screw threads to mount the scanner to customer specific fixtures.







