Farr KT5500 - Page 109

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
5.33
TECHnICaL ManuaL
Item Type Description Qty Part Number
A Weldment LHFrontLegMount 1 101-0787
B Part 7/16”NCx31/2”HexBolt 4
C Part 7/8”NFThinNylockNut 4 09-5722
D Part SupportLeg 2 1364-909
E Part FrontLegSpringTopCap 2 101-4489
F Part FrontLegSpring 2 1302-905-08
G Part BottomLegCap 2 1302-905-03A
H Assembly SupportRollerShaft 4 101-3944
I Weldment 2”LoadCellHolder 1 01-9116D
J Part 1/2”NCx6”HexBolt 4 09-1190
K Weldment RHFrontLegMount 1 101-0786
L Weldment RearBackupLegSpringPlate(Top) 1 101-4495
M Part 1/2”HexNut 4 09-9124
N Weldment RearBackupLegSpringPlate(Bottom) 1 101-4496
O Part HeavyHexBolt 1 101-0040
P Part 7/8”NCx7”HexBolt 1
Q Part 0.148”x2.938HitchPin 2
R Part 11/4”HexNut 2 09-5832
S Part 7/8”NarrowPlainWasher 2 09-5123
T Part 7/8”HexNut 2 09-5822
U Part 3/8”NCx9”HexBolt 2
V Weldment RearBackupLeg 1 101-4487
W Part DoorStopSpring 2 997-13
LEg aSSEMBLIES
