Farr KT5500 - Brake Band Assembly

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
5.21
TECHnICaL ManuaL
BRaKEBanD aSSEMBLy
Item Type Description Qty Part Number
A Part 3/8”NCx3/4”HexBolt 2 09-1044
B Part 3/8”CarbonSteelLockWasher 2 09-5106
C Part BrakeBandRetainer 1 101-0140
D Assembly BrakeBand,Lined 1 1064-D4-29
E Part 3/8”NFHexNut 2 09-5906
F Weldment LHBrakeBandLugWeldment 1 101-0134
Weldment RHBrakeBandLugWeldment 1 101-0132
G Part 3/8”NFx1-1/2”BrakeBandAdjustmentBolt 2 09-1553
