Farr KT5500 - Support Roller

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
5.5
TECHnICaL ManuaL
SuppoRT RoLLER
Item Type Description Qty Part Number
A Part 1/4”UNFStraightGreaseFitting 1 02-0097
B Part
SupportRollerShaft
(1)
1 101-3942
Part SupportRollerShaft(BackupReadyTongsOnly) 1 101-3943
Part DoorPivotRollerShaft 1 101-3944
C Part
7/8”NarrowFlatWasher
(2)
2 09-5123
D Part SupportRollerSleeve 2 1064-182
E Part TaperedRollerBearing 2 02-0099
F Part SupportRollerShaftSpacer 1 1064-183
G Part SupportRoller 1 1064-181
H Part 7/8”UNFHexThinNylockNut 1 09-5722
(1) “Backup-ready”tongs use 5x support roller shaftPN101-3942.Usefour“long”supportrollershafts(PN101-
3944)wherecoincidentalwiththefrontlegmountweldments.ThedoorpivotshaftremainsPN101-3943.
(2) Topandbottomflatwashersarenotusedwherethesupportrollershaftiscoincidentalwiththebrakebandlug
weldments. Bottom flat washers are not used where the support roller shaft is coincidental with the front leg
mountweldments.
