D. HYDRAULIC CONNECTIONS
Apairofhydrauliclines-a1”supplylineanda1-1/4”returnline-connectthetongtothepowerunit(seeillustrationbelow).Ancillary
devices(hydraulicmotors,hydrauliccylinders,etc.)areconnectedthroughthevalveblock.
Performanyhydraulicconnectionwhenthepowerunitisnotrunning,orwhenthehydraulicpumpisdisengaged.Thepossibilityof
errorininter-changingthehighpressuresupplyhoseandthelowpressurereturnhosehasbeeneliminated,becausethesupply
sidecouplingissmallerthanthereturnside.
