Farr KT5500 - Door Latch Adjustment; Shifter Detent Force Adjustment

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
3.8
TECHnICaL ManuaL
MaInTEnanCE
2. Door Latch Adjustment
Normaloperationofthetongmaycausewearofthedoorlatch,whichwillcausethedoortodevelopaloosefitatthelatch.A
latchcamplateislocatedatthetopfaceofthedoor.Thecamplatehaseightpositioningholeslocatedona360degreebolt
circle.Thelatchcamshaftextendsdownthroughthedoorandissecuredatthetopbya3/8”hexheadbolt.Tomakeadjust-
mentsindooralignment,removethe3/8”boltandturnthecamwithawrench.Whenthedoorhasbeenadequatelyaligned,
replacethe3/8”bolt(seeillustrationnextpage).
THE DOOR IS AN IMPORTANT PART OF THE STRUCTURAL INTEGRITY OF THE TONG. IT IS
IMPERATIVE TO KEEP A SECURE FIT AT THE DOOR IN ORDER TO MAINTAIN PROPER GEAR
ALIGNMENT, AND TO MINIMIZE THE POSSIBILITY OF DAMAGE TO THE GEAR TRAIN WHEN
OPERATING THE TONG AT SPECIFIED TORQUE. A CLOSED DOOR ALSO ENSURES SAFETY OF
OPERATING PERSONNEL.
3. Shifter Detent Force Adjustment:
Overtimeweartotheshiftingshaft,weartothedetentball,andlossofspringtensioninthedetentspringmayresultinaloose
or“sloppy”fitwithinthetopshifterbushing.Thedetentpressuremaybeincreasedorotherwiseadjustedbylooseningthe7/16”
UNFlockingjamnut,andturningthe7/16”UNFdetentbolt.Shouldadequatedetentactionnotbeachieved,theshiftingshaft,
detentball,ordetentspring(orpossiblyallthree)mayneedtobereplaced(seePp.5.16-5.17).
Latch Adjustment Cam
