Farr KT5500 - Shifter Assembly

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
5.15
TECHnICaL ManuaL
SHIfTER aSSEMBLy
Item Type Description Qty PartNumber
A Weldment ShifterHandle 1 1037-D-20B
B Part 5/16”x1-1/2”ANSI/ASMEB18.8.1ClevisPin 2 09-0256
C Part BS15745/64”x5/8”CotterPin 2
D Part ShiftingShaft 1 1400-71
E Part ShifterDetentTube 1 101-0019
F Part ShifterDetentBall 1 02-0018
G Part ShifterDetentSpring 1 997-0-64
H Part 7/16”UNFHexNut 1 09-5908
J Part 7/16”UNFx1-1/4”HexBolt 1 09-1608
K Part ShiftingYoke 1 997-D13-72
L Part 5/8”NFHexJamNut 1 09-5915
M Part 5/8”NFHexNut 1 09-5914
N Part BottomShifterBushing(Typicallyweldedtobottomplate) 1 1064-B1-95
P Part 3/8”x1”HexBolt 4 09-1170
Q Part 3/8”CarbonSteelLockWasher 4 09-5106
R Weldment ShifterLugWeldment 1 101-0016
S Part TopShifterBushing(Threaded) 1 101-0020
