Farr KT5500 - Tong Jaw Availability & Installation

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
2.12
TECHnICaL ManuaL
SETup & opERaTIon
Thesehosecouplingsareself-sealing,andcareshouldbetakentoensurecompleteengagementtopreventpartialclosureofthe
checkvalveinthecoupling.Ensurethatthenut(female)sideiscompletelymadeupontothemaleconnector-thereisalineonthe
malefittingthatindicatescompletemake-up.Snugthefemalefittingrightuptotheline.
E. TONG JAW AVAILABILITY & INSTALLATION
1. Jaw Availability
Thefollowingtable lists alljawdie kits thatareavailable as standardstockedsizes for thismodelof tong. McCoyDrilling&
Completions | Farr offers a good selection of standard jaw sizes. However, please note that we can custom-engineer and
manufactureanysize of jawwithinthe range ofthetong. Jaw systemsareavailable to allowuseof die insertsintendedfor
specializedapplications.Calloursalesofficeforinformationonjawanddiesystemsdesignedforhigherorlowergrip,ornon-
markingapplications.
Thetablelistsstandardcontoured,flatandwraparounddieinsertsthatareavailableasspareparts.However,awidevariety
ofdiamond-tooth,GRITFACE®,aluminium,andwrap-aroundfine-toothdiesareavailableforspecializedapplications.Please
refertoourwebsiteforcompleteinformation:
http://www.mccoyglobal.com/index.php/dies-inserts
STANDARD JAW DIE KITS (Inserts Not Included)
Description Part Number
2-3/8”JawDieKit
(1)
1064-JDK-65
2-7/8”JawDieKit
(2)
1064-JDK-70
3”JawDieKit
(3)
1064-JDK-71
3-1/2”JawDieKit 1064-JDK-75
4”JawDieKit 1064-JDK-80
4-1/2”JawDieKit 1064-JDK-85
5”JawDieKit 1064-JDK-90
5-1/2”JawDieKit
(4)
1064-JDK-95
(1)
Uses2.375”ContourDie 12-1004
(2)
Uses2.875”ContourDie 12-1007
(3)
Uses3.5”ContourDie 12-1011
(4)
Uses1”x3.875”FlatDie 12-1003
AllotherStandardDieKitsuse1-1/4”x3.875”FlatDie 13-0008-314-0
Continued On Next Page
Make up female fitting to
Marked point on male fitting
