Farr KT5500 - Backup Body (Tension Lc Configuration)

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
5.39
TECHnICaL ManuaL
Low-pRofILE BaCKup BoDy aSSEMBLy -
CoMpRESSIon LC ConfIg
Item Type Description Qty Part Number
A Weldment BackupBody 1 1421-500-LP
B Weldment 2”LoadCellHolder 1 01-9116 D
C Part ReliefValveBody 1 08-1839
D Part BCJBody 1 08-1327
E Part RearCoverPlate 1 101-4482
F Part 3/8”NCx3/4”HexBolt 16 09-1044
G Part 3/8”LockWasher 16 09-5106
H Part FrontCoverPlate 2 1421-500 -11
I Part 3/8”NCx11/4”HexBolt 1 09-1048
J Part 1”NCx9”HexBolt 4 09-0288
K Weldment GaugeProtectorWeldment 1 1483-500-18
L Part CLINCHER®RearJaw 1 1403-08
M Assembly CLINCHER®CylinderAssembly 2 1403-00-00B
N Part RearCoverPlate 1 101-4481
Part 3000PSIPressureGauge(NotShown) 1 02-0245
