Farr KT5500 - Lubrication

KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
3.2
TECHnICaL ManuaL
MaInTEnanCE
D. LUBRICATION
Useaqualitymultipurposebearinglubricantthatwillremainwithinitsviscosityrangeatexpectedoperatingtemperatures.Inaddition,
Farrrecommendsthefollowinglubricationprocedureatthecompletionofeachjobpriortostorage.
1. Cage Plate Cam Followers
Applygreasetothegreasefittingsrecessedinboththetopandbottomcageplates(26locationstotal-13top/13bottom).
2. Support Rollers
Applygreasetothesupportrollerbearingsthroughthegreasefittingsrecessedintothetopofeachsupportrollershaft.NOTE:
thesafetydoorcamassemblyneedstoberemovedtoaccessthegreasefittinginthetopofthedoorpivotrollershaft(ten
locationstotal).
