” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
6.2
TECHnICaL ManuaL
Item Type Description Qty Part #
Assembly 30”Arm-20KTensionLoadCellandGauge 1 10-0028T
A Part 4.08in
2
TensionLoadCell 1 10-0008T
B Part TorqueGauge,20,000Ft.-Lbs.36”Arm 1 10-0028G
C Part HydraulicHose 1 02-0069
Item Type Description Qty Part #
Assembly 32”Arm-20KCompressionLoadCellandGauge 1 10-0029C
A Part 8in
2
CompressionLoadCellc/whoses&fittings 1 10-0008C
B Part TorqueGauge,20,000Ft.-Lbs.,32”Arm 1 10-0029G
C Part HydraulicHose 1 02-0069
THE TORQUE GAUGE USED IS FULLY DEPENDANT UPON THE ARM LENGTH AND TORQUE
RANGE OF THE EQUIPMENT IN USE. THE PART NUMBERS LISTED IN THE FOLLOWING TABLES
ARE CORRECT FOR ACCURATELY MEASURING TORQUE USING THE EQUIPMENT FOR WHICH
THIS MANUAL IS SUPPLIED.
BASIC TORQUE MEASUREMENT (Continued:)
Theimagesontheprecedingpageareforillustrationpurposesonlyandmaynotaccuratelyrepresentthetorquegaugeandloadcell
thathavebeensuppliedwithyourequipment.Pleasenotethatthepartslistedinthefollowingtablearecorrectforaccuratetorque
measurementwhileusingtheequipmentforwhichthismanualissupplied.
ToRquE MEaSuREMEnT
