KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
1.3
TECHnICaL ManuaL
SpECIfICaTIonS
** THESE ARE IDEAL VALUES. ACTUAL ACHIEVED TORQUE IS HIGHLY DEPENDANT UPON
TONG EFFICIENCY AND FINAL POSITION OF ROTARY GEAR WHEN FULL TORQUE LOAD IS
REACHED.
Maximum Hydraulic Requirements: 60 US GPM (227.1 LPM)
2500 psi (17.2 MPa)
Length (Doors Closed): 52” inches / 132.1 cm
Height: 60” / 152.4 cm
Width: 37” / 94 cm (Model 80-0421-3 Tension LC)
34” / 89 cm (Models 80-0422 & 80-0406 Comp. LC)
Torque Arm Length: 30 inches / 76.2 cm (Tension Load Cell Configuration)
32 inches / 81.3 cm (Compression Load Cell Configuration)
- Centre line of pipe to centre line of anchor -
Weight (Approximate, without jaws): 2050 lb. / 932 kg.
Recommended Spring Hanger: 85-0106XXH (Capacity = 3500 lbs./1591 kg.)
Casing Jaws Available (inches): See Pp. 2.12 - 2.14
Torque Table **
Pressure High Gear Low Gear
PSI / MPa Lbs.-ft. Nm Lbs.-ft. Nm
1000 / 6.89 1530 2074 7650 10372
1400 / 9.66 2250 3050 11250 15253
1800 / 12.41 2970 4027 14845 20127
2250 / 15.513 3780 5125 18894 25617
MAXIMUM RATED TORQUE: 18700 LBS.-FT. / 25354 Nm
Speed Table (Single Speed Motor)
Flow (US GPM / LPM) Low Gear (RPM) High Gear (RPM)
10 / 37.9 2.7 13.4
20 / 75.71 5.4 26.8
40 / 151.4 10.7 53.6
60 / 227.1 16.1 80.5
ALL REPLACEMENT FASTENER (BOLTS, NUTS, CAP SCREWS, MACHINE SCREWS, ETC.) USED
DURING MAINTENANCE OR OVERHAUL MUST BE GRADE 8 OR EQUIVALENT UNLESS OTHER-
WISE SPECIFIED.
